At the beginning of 2007, Scotsman launched the new Super-flake ice machine MF83 for fishery and food processing applications.
The capacity production of the new model is 2,300kg/24hat +10°C air / +10°c water.
The new model is a new design and has many advantages, including:
• Stainless steel scotch-brite finish, with rounded edges for durability and easy cleaning, supplied with legs and top cover in ABS
• Height reduced, other dimensions unchanged and weight reduced for easier installation and movement
The cover and ice chute are manufactured in ABS and can be multiplexed with KICMAREXT, to allow ice to fall into the storage bin/cold room. The ice spout can be repositioned onto the side of the machine, if required.
The refrigeration circuit has been simplified using a new model of DORIN compressor.
The condenser position has also been reviewed to aid maintenance, cleaning and service.
The gear motor has been selected for high mechanical loads and designed with a high safety margin for high production capacity.
The control panel is designed to comply with electrical requirements and to enhance equipment performance.
Additional to the standard components already provided (contactors, pressure switches, thermostats, terminal boards, cabling), the following have also been included:
• Electrical supply check on input phases sequence – with alarm light
• Compressor start delay (drive motor starts immediately)
• Drive motor stop delay (after compressor stop)
In addition to this range, the Split version will be available – MF83Split. This model allows the use of a remote condensing unit or central cooling systems.
This version is IP55 rated, allowing the machine to be installed in damp or food processing areas where it is necessary to use high pressure water for cleaning.
